RMG/A‑RMG

RMG — Rail Mounted Gantry Container Crane.

A-RMG — Automated rail mounted gantry container crane.

The RMG container crane offers high efficiency and reliability, with electric-driven main operation movements. It can be configured with rotary or non-rotary trolleys, and with or without cantilevers, suitable for use in container terminals and ports. With a lifting capacity up to 50 tons, crane gauge up to 80 meters, and a lift height of 26 meters, it handles any heavy loads effectively.

The A-RMG version features fully automated operation mode for even higher productivity.

RMG/RTG crane models:

TECHNICAL

SPECIFICATIONS

Load lifting capacity 1
Under the spreader 43 t
Under the pulley frame50 t
Crane gauge 225 m
Trolley gauge15,6 m
Trolley wheelbase2,52 m
Distance between gantry legs in the load passage zone15,5 m
Right and left consoles reach 36 m
Maximum load per wheel22,5 t
Spreader turning angle360°
Crane operation speeds
Maximum load lifting/lowering speed30 m/min
Lifting/lowering speed without cargo60 m/min
Maximum load trolley traveling speed100 m/min
Maximum load crane traveling speed120 m/min
Maximum load slewing speed2 rpm
Crane operation mode category as per ISO 4301/1 during transshipment of:
Containers, gross weight 30.5 tA8
Containers, gross weight 43 tA5
Breakbulk cargo, gross weight up to 50 tA5

1 Possibility of capacity increase up to 50 t
2 Possibility of extension up to 59 m
3 Possibility of extension up to 16 m
