RPS-1600

FULLY ELECTRIC DOUBLE JIB LEVEL LUFFING CRANE

The RPS-1600 is Double Jib Level Luffing crane with the highest lifting capacity in the RIKON RPS lineup, with an outreach of up to 60 meters, a lifting capacity of up to 200 tons in hook mode, 52 tons in grab mode, and an output of up to 1500 tons per hour in grab mode is erfectly suited for a wide range of cargo handling tasks in hook, grab, magnet, lifting beam, and spreader modes. The RPS-1600 is an ideal solution for seaports, river ports, terminals, and industrial facilities.

The RPS‑1600 can also be realized with a slewing bearing design, as illustrated by the RPS‑300 model.

RPS/RSC crane models:
Performance of up to
1600
tons/hour

TECHNICAL

SPECIFICATIONS

Boom reach 1
Minimum9 m
Maximum 40 m
Load lifting capacity
Grab mode 2
 at boom reach 40-9 m 32 t
Hook mode 3
 at boom reach 40-25 m40–63 t
 at boom reach 25-9 m63 t
Crane gauge 410,5 m
Maximum load per wheel23 t
Crane weight490 t
Crane wheelbase10,5 m
Lifting height
with grab29 m
with hook32 m
Lowering depth
with grab23 m
with hook20 m
Superstructure tail radius7,5 m
Operating speeds
Lifting and lowering64 m/min
Turning1,4–1,7 rpm
Luffing60 m/min
Traveling20 m/min
Operation mode according to ISO 4301/1A8

1 Possibility of extension up to 55 m
2 Possibility of increasing lifting capacity in bucket mode up to 50 t
3 Possibility of increasing lifting capacity in hook mode up to 200 t
4 Possibility of gauge increase up to 15.3 m

Lifting capacity depending on boom outreach
