RPS-300

FULLY ELECTRIC DOUBLE JIB LEVEL LUFFING CRANE

The RPS-300 is the smallest model in the series of fully electric Double Jib Level Luffing cranes, combining compact design with high efficiency. With an outreach of up to 36 meters, a lifting capacity of up to 25 tons in hook mode, 12 tons in grab mode, and an output of up to 400 tons per hour in grab mode, it is perfectly suited for a wide range of cargo handling tasks especially in space-limited environments. Designed for use in hook, grab, magnet and lifting beam modes, the RPS-300 ensures reliable and flexible operation when handling both general and bulk cargo.

The Double Jib system is offering excellent efficiency and precision. All core movements — including boom luffing, lifting and lowering of cargoes, slewing, and travelling — are powered by electric drives with energy recovery system, delivering smooth performance, high productivity, and low environmental impact.

RPS/RSC crane models:
Performance
 of up to
400
tons/hour

TECHNICAL

SPECIFICATIONS

Boom reach 1
Minimum8 m
Maximum 30 m
Load lifting capacity
Grab mode
 at boom reach 40-9 m 10 t
Hook mode 2
 at boom reach 40-25 m10-20 t
 at boom reach 25-9 m20 t
Crane gauge 310,5 m
Maximum load per wheel22,5 t
Crane weight160 t
Crane wheelbase10,5 m
Lifting height
with grab20 m
with hook22 m
Lowering depth
with grab15 m
with hook15 m
Superstructure tail radius7,0 m
Operating speeds
Lifting and lowering64–90 m/min
Turning1,6–2,2 rpm
Luffing64 m/min
Traveling20 m/min
Operation mode according to ISO 4301/1A8

1 Possibility of boom outreach extension up to 36 m
2 Possibility of lifting capacity increase in hook mode up to 30 t
3 Possibility of crane gauge increase up to 15.3 m

Lifting capacity depending on boom outreach
