RPS-640

FULLY ELECTRIC DOUBLE JIB LEVEL LUFFING CRANE

The RPS-640 features increased specifications, with an outreach of up to 40 meters, a lifting capacity of up to 40 tons in hook mode, 18 tons in grab mode, and an output of up to 650 tons per hour
in grab mode is perfectly suited for a wide range of cargo handling tasks in hook, grab, magnet, lifting beam, and spreader modes.

The RPS‑640 can also be realized with a slewing earing design, as illustrated by the RPS‑300 model.

RPS/RSC crane models:
Performance of up to
650
tons/hour

TECHNICAL

SPECIFICATIONS

Boom reach 1
Minimum8 m
Maximum 30 m
Load lifting capacity
Grab mode
 at boom reach 40-9 m 10 t
Hook mode 2
 at boom reach 40-25 m10-20 t
 at boom reach 25-9 m20 t
Crane gauge 310,5 m
Maximum load per wheel22,5 t
Crane weight160 t
Crane wheelbase10,5 m
Lifting height
with grab20 m
with hook22 m
Lowering depth
with grab15 m
with hook15 m
Superstructure tail radius7,0 m
Operating speeds
Lifting and lowering64–90 m/min
Turning1,6–2,2 rpm
Luffing64 m/min
Traveling20 m/min
Operation mode according to ISO 4301/1A8

1 Possibility of boom outreach extension up to 36 m
2 Possibility of lifting capacity increase in hook mode up to 30 t
3 Possibility of crane gauge increase up to 15.3 m

Lifting capacity depending on boom outreach
