RSC-630

MOUNTING CRANE

The RSC‑630 is a Mounting crane designed for shipbuilding operations, including sectional mounting, assembly work, and the lifting and handling of single unit loads. The Double Jib system is offering excellent efficiency and precision. All primary movements, such as boom uffing, lifting and lowering of loads, slewing, and traveling, are powered by electric drives, delivering smooth performance, high productivity, and low environmental impact. The cranes are equipped with the Micromotion system and are perfect for complex installation operations.

The RSC‑630 combines advanced engineering with practical high performance and reliability, making it an essential tool for shipbuilding companies and shipyards for completion and assembly operations. The crane has a main hoist lifting capacity of up to 500 tons and an auxiliary hoist lifting capacity of up to 50 tons, with a boom outreach of up to 100 meters and a lifting height of up to 100 meters.

RPS/RSC crane models:

TECHNICAL

SPECIFICATIONS

Boom reach
Main hoist 1
 minimum9 m
 maximum 45 m
Auxiliary hoist
 minimum11 m
 maximum 48 m
Load lifting capacity
Main hoist 2
 at boom reach 45-20 m 8-30 t
 at boom reach 20-18 m30-35 t
 at boom reach 18-9 m35 t
Auxiliary hoist 3
 at boom reach 48‑11 m6 t
Crane gauge10,5 m
Maximum load per wheel35 t
Crane weight350 t
Crane wheelbase13 m
Lifting height 4
Main hoist50 m
Auxiliary hoist50 m
Lowering depth
Main hoist17 m
Auxiliary hoist17 m
Superstructure tail radius7,5 m
Operating speeds
Main hoist lifting/lowering10 m/min
Auxiliary hoist lifting/lowering40 m/min
Turning0,5 rpm
Luffing40 m/min
Traveling30 m/min
Operation mode according to ISO 4301/1A6

1 Possibility of main hoist extension up to 100 m
2 Possibility of increasing main hoist lifting capacity up to 500 t
3 Possibility of increasing auxiliary hoist lifting capacity up to 50 t
4 Possibility of increasing lifting height up to 100 m

Lifting capacity depending on boom outreach
